The Stud Mounted ABR is designed to fit the Desert Tech rifles. The ABR mounts to the supplied stud that replaces the monopod. Due to the different frame sizes - the ABR could be underneath the magazine on the smaller models (making it a single feed). A loading block may be required for the smaller frames and is recommended on larger frames to allow more clearance for the adjustment hand. For the loading block link click here.It provides the same superior functionality as the other ABRs. It ships with the Anodized Stud (that needs to be installed first) that has a hole through it to allow the insertion of a rod for tightening the stud into the frame. The ABR has a 1/4-28 bolt for clamping to the stud (torque to 10 lbs/ft). Available with the ELR bottom or the V bottom The ‘Bag Selection’ page goes over the lower rider differences.

• A new ‘Quick adjustment’ thread option (Coarse thread) is available for PRS, Hunting - use requires Hardened Dowels

Made in America from American 6061-T6 alum and Black Anodized Class II

Please note that this product will not fit other Rifles without modification.

Non-Affiliation Disclaimer. We are not affiliated, associated, authorized, endorsed by, or in any way officially connected with the Desert Tech brands .

FAQ’s

“Which MODEL do I choose?”

• DT-Combo-Long-ELR has a wider shorter base which allows for a lower shooting position

• DT-Combo-Long-V has a V' shaped bottom which fits a standard two stitch shooting bag.

“Which DOWELS do I choose?”

• .338 and smaller calibers will use the StandardDowels

• .33XC and larger needs the Hardened Dowels

• PRS needs Hardened Dowels
